Light Duty Aluminum Traffic Door

$0.00

Suitable for hand cart traffic

This door is constructed of high density, textured USDA Accepted polyethylene, gravity hinge system, and a stainless steel back channel. Standard features include a 9” x 14” acrylic window.

Options consist of various window configurations, molded spring bumpers, stainless steel impact plates, perimeter gasketing, and an array of colors. The Light Duty Traffic Door is a great high quality, cost effective door solution for your light duty application.

Ideal for: Retail or Commercial Applications with light personnel and cart traffic

Click To Learn What A Finished Opening Is And How To Measure For Your Door

Finished Opening (Inches): W x H required

Hinge Side required

Window Options required

9" x 14" Window (Included) 12" Round Window 15" Round Window 22" x 22" Window

Full Perimeter Gasket required

Yes No

Door Frame required

See Frame Spec Sheet In Images

None Galvanized Steel Frame: 4-7/8" Wall Thickness

Quantity

Not seeing what you need?
Want some help building a custom door?

Product Description

This door is constructed of high density, textured USDA Accepted polyethylene, gravity hinge system, and a stainless steel back channel. Standard features include a 9” x 14” acrylic window.

Ideal for: Retail or Commercial Applications with light personnel and cart traffic

Door Type: Aluminum Clad Solid Core Traffic Door
Door Size: Available to fit openings up to 96" x 96"
Construction: Sustainable, moisture resistant wood core and clad full height on both sides with aluminum alloy and 48" high impact plates
Hinge: Gravity Hinge System
Window: Standard scratch resistant 9" x 14" acrylic, set in rubber molding
Door Thickness: 1"
Core: .75" thick sustainable, moisture resistant, wood core
Back Channel: Stainless Steel Back Channel
Gasketing: Optional
Finish: Tempered Aluminum Alloy with Satin Anodized Finish with 48äó high stainless steel base plates (both sides)
Impact Plates: Standard 48" Stainless Steel Impact Plates
Options: Various Window Configurations (9" x 14", 12", 15", 22" x 22"), Full Perimeter Gasketing
Colors: Aluminum
Traffic: Personnel and Light Cart Traffic
Applications: Restaurants, Retail, Commercial, Institutional
